Features:
- Innovatively designed metal housing in MIPRO’s aesthetics and ergonomic style.
- Basic sterling gray color with other custom-made colors optional.
- Turn upper housing for 2 AA battery installation and replacement.
- Interchangeable capsule module with premium condenser or dynamic options for easy and fast changeovers.
- The unique multi-layered metal grille protects the capsule against impact, rolling and pop noise, ensuring clarity of sound.
- Backlit LCD displays all operational parameter information.
- Five selectable gain settings with microphone input sensitivity of 0 dB.
- Switchable Manual /Disable audio mute options.
- Switchable High/Low power options.
- The bottom housing with built-in high-efficiency antenna features power switch, mute and setup buttons for programmable gain, limiter, low-cut and RF output power.
- Patented end-cap covers with color-coded channel identification clips. Detach the end-cap cover for parameter set-up. Reversible end-cap allows shielding of power on/off or mute switches during performance.
- High-efficiency circuitry design provides 12~14 hours of operation from 2 AA batteries (depending on the battery quality)
Specifications:
Frequency Range | UHF 480 – 934 MHz (country dependent) |
Bandwidth | 72 MHz |
Channel Set-Up | ACT Sync |
RF Output Power | 10 mW / 50 mW (switchable) |
Deviation | < ±40 kHz |
Spurious Emissions | ≦ -60 dBc |
Oscillation Mode | PLL Synthesized |
Frequency Stability | ≦ ±0.005% (-10 – +60℃) |
LCD Display | Group, Channel, Frequency, AF gain, Frequency band, RF power, Mute mode, Battery status and error codes |
Gain Setting | +6 dB, +3 dB, 0 dB, -3 dB, -6 dB (5 settings) 0 dB = input microphone sensitivity |
Max. SPL | 142 dB SPL |
Battery Type | 2 AA alkaline |
Operating Time | Min. 12 hours (Low Power) |
Current Consumption | High Power: approx. 161 mA ; Low Power: approx. 120 mA |
Dimensions | 51 × 258 mm / 2 × 10.1 ” (Ø × L) |
Net Weight | Approx. 292 g / 10.3 oz |
