JBL KX180 Professional-Grade Digital Processor

Professional-Grade Digital Processor

KX180 is a professional-grade digital processor designed for karaoke applications and provides a full set of audio processing for enhancing or fine-tuning music and voice. KX180 is equipped with three 6.5mm connectors for microphone input, two groups of RCA connectors and an optical connector for music input, and one pair of RCA connectors for recording out. It supports storage and recall of up to 10 presets and manual or auto control of Dance or Sing mode.


  • Two groups of microphone inputs
  • 15-band PEQ and compressor for each Mic Input
  • Three levels of Feedback Inhibition for each Mic Input
  • Independent control of Echo and Reverberation
  • Two pairs of RCA connectors and an Optical connector for Music Input
  • 15-band PEQ for Music Input
  • Three levels of Excitement for Music Input
  • Six output channels: Right, Left, Centre, Sub, Surround Right and Surround Left.
  • 10-band PEQ for Right and Left Outputs
  • 7-band PEQ for Surround and Centre Outputs
  • 5-band PEQ for Subwoofer Output
  • Compressor provided for each output channel
  • Two independent REC channels can be paired into stereo
  • Authority control for front panel controls
  • Up to 10 presets can be saved
  • Dance or Sing mode of each microphone input channel can be switched manually or automatically
  • Professional tool designed for karaoke applications.SPECIFICATIONS
    Mic Input Type 3 x 1/4” unbalanced
    Impedance 7.5K Ohms
    Level Control –∞ to +0.8dBu
    Line Input Type RCA unbalanced, left & right
    XLR Output Type Unbalanced
    Level 0dBu Nominal, +14.2dBu Maximum
    RCA Output Type Unbalanced, left & right
    Frequency Response 20Hz~20KHz ≤ ±1.0dB
    THD+N <0.06% 20Hz to 20KHz
    Dynamic Range >100dB
    A/D Conversion 24bit, 48KHz
    DSP Processor High performance 32-bit/40-bit floating-point processor
    Carrier Frequency 38KHz
    Format NEC
    Distance Device dependent
    Angle Device dependent
    Computer Connection USB 2.0
    AC Power Supply AC 220V/50Hz
    Dimensions (W X D X H) 485 X 205 X 47mm
    Net Weight 2.8Kg
    Gross Weight 3.47Kg
