Crown XLi Series Power Amplifier


SKU: N/A Category: Tag:

XLi Series

Two-channel, Power Amplifier

The XLI Series of power amplifiers from Crown® represents a new era in affordable, quality power amplification. All four models in the series are powerful, rugged and reliable. They are suited for musicians, DJs, and entertainers as well as houses of worship, discos, and pubs.

The four models in the series are the XLi800, XLi1500, XLi2500 and XLi3500. They are identical except for output power.

Features include RCA and XLR inputs, user selectable input sensitivity of 0.755V or 1.4V, Speakon® and binding post outputs, stereo/parallel/bridge-mono mode, power/fault/signal presence/clip indicators, forced-air cooling; and protection against shorts, no-load, on/off thumps and radio-frequency interference.

With over six decades of experience designing and building rock-solid products, Crown is the standard in amplifier technology. So check out the affordable Crown XLI Series. They are a powerful argument for quality and value!

Crown® 的 XLI 系列功放开创了提供质优价廉产品的新时代。 此系列四个型号均有着性能强大、结构坚固且可靠的特点, 是音乐家、DJ、艺人以及教堂、迪斯科和酒吧等的理想解决方案。

这四个型号分别为 XLi800、XLi1500、XLi2500 和 XLi3500, 除输出功率外配置完全相同。

特色包括 RCA 和 XLR 输入、用户可选择的 0.755V 或 1.4V 输入灵敏度、Speakon® 和输出接线柱、立体声/并联/桥式单声道模式、电源/故障/信号检测/削波指示灯、强制风冷以及短路、空载、开/关低频噪音和无线电波干扰保护。

凭借着六十多年磐石般的产品设计和制造经验,Crown 现已成为功放技术的标准。 请查阅经济实惠的 Crown XLI 系列。 物美价廉的最佳代言人!

Power Matrix


  • Stereo/parallel/bridge-mono mode
  • User selectable input sensitivity – 0.775V and 1.4V
  • Efficient forced-air cooling prevents excessive thermal buildup
  • Electronically balanced RCA & XLR inputs; binding post and Speakon outputs
  • Two level controls, power switch, power LED, and six LEDs which indicate signal presence, clip and fault for each channel
  • Protection against shorts, no-load, on/off thumps and radio-frequency interference


  • 立体声/并联/桥式单声道模式
  • 用户可选择的输入灵敏度 – 0.775V 和 4V
  • 高效的强制风冷可防止设备过热
  • 电子均衡 RCA 和 XLR 输入;接线柱和 Speakon 输出
  • 两个电平控件、电源开关、电源 LED 以及六个可显示每个声道是否有信号、削波和故障的 LED 指示灯
  • 短路、空载、开/关低频噪音和无线电波干扰保护


Frequency Response 20 Hz – 20 kHz, +0/-1 dB (at 1 watt)
THD <0.5%, 20 Hz – 20 kHz
Intermodulation Distortion =/ <0.35% (60 Hz and 7 kHz at 4:1 from full rated ouput to -30 dB)
Slew Rate >10V/us
Voltage Gain 36 dB
Damping Factor (8 ohms, 10 Hz to 400 Hz) >200
Signal To Noise Ratio (A-weighted) >100 dB
Crosstalk (below rated power) 20 Hz to 1 kHz -75 dB, -59 dB
Input Sensitivity (for full rated power at 8 ohms) 0.775V or 1.4V
Input Impedance (nominal balanced, unbalanced) 20kΩ, 10kΩ
AC Line Voltage and Frequency Configurations Available (+10%) 120V~60 Hz; 220V~50/60 Hz; 230-240V~50/60 Hz
Dimensions 19″ x 3.5″ x 14.4″ (48.3cm x 8.9cm x 36.6cm)
Weight 43lbs (19.5kg)
IEC Power Connector 15A

XLi3500, XLi2500, XLi1500, Xli800
